        Portable Anti Drone Signal Jammer

        A portable anti drone signal jammer is a device designed to disrupt the communication between a drone and its operator, effectively neutralizing its ability to fly or carry out its intended mission. It works by emitting radio frequency signals that interfere with the remote control signals or GPS signals used by the drone.

        Send Inquiry

        Product Description

        This Portable Anti Drone Signal Jammer is a professional drone defense system, quite effective against the drone and UAV. TeXin developed this portable drone jammer totally with our own research and development team. It can shield the drone and force the drone return home or land in range up to 3000 meter.

        While Portable Anti Drone Signal Jammer can provide general information, it's important to note that the use and legality of such devices can vary depending on your location. In many countries, the use of signal jammers is strictly regulated or prohibited due to concerns about potential interference with legitimate communication systems.

        If you are in a situation where the use of an anti-drone signal jammer is allowed, it's important to understand some key considerations:

        Range: Portable signal jammers typically have a limited range of effectiveness. The range can vary depending on the specific device, but it's generally a few hundred meters. It's crucial to ensure that the device you choose has a range sufficient for your intended application.

        Frequencies: Drones can operate on different frequencies, including common ones such as 2.4 GHz and 5.8 GHz for remote control, as well as GPS frequencies. When selecting a signal jammer, make sure it covers the frequencies used by the drones you are targeting.

        Battery Life: Portable signal jammers are powered by batteries. Consider the battery life and charging requirements to ensure the device remains operational for the duration needed.

        Legality: As mentioned earlier, the use of signal jammers can be restricted or illegal in many jurisdictions. It's important to research and understand the laws and regulations regarding signal jammers in your area before using or purchasing one.

        Ethical considerations: While anti-drone signal jammers can be useful in certain situations, it's important to use them responsibly and ethically. Ensure that you have a valid and legal reason for using such a device, such as protecting sensitive areas or maintaining privacy, and avoid interfering with legitimate communication systems.

        Lastly, it's worth mentioning that the development of drone technology is rapidly advancing, and drone manufacturers are continuously working on ways to counter signal jamming and improve their drones' resistance to interference.

        Portable Anti Drone Signal Jammer Specification

        Item No.

        TX-KJ01

        Size

        594*488*180mm

        (The draw is 475mm when is pull out)

        Weight

        22.0KG

        Jamming Frequency

        Customized 433 900 GPSL2 1.2 GPSL1 1.5 2.4 5.8G

        (Mobile phone GPS signal jammer type is available too )

        Total output power

        Over 300W

        Large jamming range

        Up to 3000 Meter, depends on real signal environment

        ( FH frequency drone is2000meter such as DJI mavic3 )

        Power supply

        AC100-240V / DC24V

        BatteryCharge time

        3-4 Hour

        Built-in Lithium Battery

        Built-in battery

        24V 40A

        ( External Battery can be offered with extra cost )

        Battery Last time

        60-70 minutes

          Work temperature

        -22℃ to +60℃


        Portable Anti Drone Signal Jammer advantage

        *Easy Operation

        *Up to 3000 meter jamming range for drone UAV

        *Fast move with wheels

        *Over 1 hour built in lithium battery

        *Rechargeable


        Portable Anti Drone Signal Jammer packing list

        > Portable drone jammer *1 piece

        > AC charger *1piece

        > DC charger *1piece


        anti drone signal jammer TX-KJ01


        anti drone signal jammer TX-KJ01
